TRANE COM6428 Sweat Compressor 200V 3-Phase 10 Ton

Product Description

The Trane COM6428 is a sweat compressor built for air conditioning systems. This compressor is designed for 200V, 3-phase power and provides a refrigeration capacity of ten tons. It is made from cast iron which ensures durability and longevity.

• Configured for commercial and industrial air conditioning applications.
• Equipped with brazed stub tubes for dependable refrigerant flow.
• Operates at a speed of 3450 RPM to achieve high pressure and temperature outputs.

Product Highlights

Ideal for use in various HVAC systems, the Trane COM6428 features a hermetic design for efficiency in refrigerant compression.

Product Information

Standard Information

• Brand: Trane
• MPN: COM6428

Technical Specifications

• Voltage: 200V
• Phase: Three
• Refrigeration Capacity: 10 Ton
• Length: 24 inches
• Discharge Size: 7/8 inches
• Material: Cast Iron
• Mounting Type: Spacer Solid
• Refrigerant: R-22
• Speed: 3450 RPM
• Type: Hermetic, Positive Displacement
• Connection Type: Brazed, Stub Tube
• Frequency: 60 Hz
• Oil Type: Mineral Oil
• Pressure: 300 PSI
• Temperature: 54.4°C
• Weight: 197 lbs
