Trane TTA07243DAAE02P Condensing Unit 6 Ton 3-phase

Product Description

The TRANE TTA07243DAAE02P is a commercial air-cooled split system condensing unit rated at 72,000 BTU/h (6 tons) of cooling capacity. This unit runs on 208/230-volt three-phase power and uses R-410A refrigerant. It is designed for the outdoor portion of a split cooling system, rejecting heat from the refrigerant circuit to the surrounding air. HVAC technicians and mechanical contractors install this unit as part of a commercial or light-commercial cooling system where single-phase power is not available or where load requirements call for three-phase electrical service.

This condensing unit is suited for commercial and light-commercial cooling applications where a 6-ton capacity is required. Three-phase power availability makes it a practical fit for office buildings, retail spaces, and similar commercial environments. It pairs with a compatible indoor air handler or evaporator coil to complete the refrigerant circuit. Installation is performed by licensed HVAC technicians following local mechanical and electrical codes.

Key Features

• 72,000 BTU/h (6-ton) cooling capacity for commercial load requirements
• Three-phase 208/230-volt operation for commercial electrical services
• R-410A refrigerant system — no ozone-depleting chlorine compounds
• Air-cooled condenser design suitable for standard outdoor installation
• Split system configuration pairs with a separate indoor evaporator coil or air handler

Compatibility

Designed as an OEM split system condensing unit for commercial cooling applications requiring 6-ton capacity and three-phase power. Consult the equipment schedule and manufacturer documentation to confirm compatible indoor coil or air handler pairings before ordering.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification for R-410A refrigerant handling. Disconnect and lock out all electrical power before servicing. Three-phase wiring connections must comply with the NEC and local electrical codes. The unit must be set on a level pad with adequate clearance on all sides per manufacturer specifications to ensure proper airflow and serviceability.

Technical Specifications

• Unit Type: Cooling
• Cooling Capacity: 72,000 BTU/h (6 tons)
• Tonnage: 6 tons
• Voltage: 208/230 volts, 3-phase
• Refrigerant: R-410A

Standard Information

• Brand: TRANE
• Manufacturer Part Number: TTA07243DAAE02P
