Tool-flo 593862RN4C Grooving Insert GP50 Solid Carbide Tin

Product Description

The TOOL-FLO 593862RN4C is a solid carbide grooving insert in the Flo-Lock series, designed for precision grooving and parting operations on CNC lathes and turning centers. This right-hand insert carries a GP50 manufacturer grade with a PVD-applied TiN coating, offering wear resistance on steel and similar workpiece materials. The cutting width measures 0.1252 inches (3.18 mm) with a maximum depth of cut of 0.1799 inches (4.57 mm). The full-radius geometry and positive rake angle support clean chip formation and reduced cutting forces during interrupted or continuous grooving passes. Machinists and toolroom technicians working with ferrous materials will find this insert suited to tight-tolerance groove profiles.

This insert is intended for use in Flo-Lock compatible grooving toolholders and cartridges on turning equipment. Its ISO code FLRP-3062R identifies the insert style and size, making cross-referencing to compatible holders straightforward. The 3/8-inch (0.3750-inch) gage diameter and insert size code 3062 align with standard Flo-Lock system tooling setups. Primary workpiece material is steel, with the GP50 grade and TiN finish providing a balance of toughness and surface hardness appropriate for general turning shop production environments.

Key Features

• Solid carbide construction with PVD TiN coating for wear resistance on steel
• Cutting width of 0.1252 inches (3.18 mm) for precise groove sizing
• Maximum depth of cut of 0.1799 inches (4.57 mm); rated range 0.1500 to 0.2000 inches
• Full-radius geometry with positive rake angle for efficient chip evacuation
• Right-hand cutting orientation; ISO code FLRP-3062R
• GP50 grade with C5/C6 material grade classification for general steel applications

Compatibility

Designed for use with Flo-Lock series grooving toolholders and cartridges accepting FLRP-3062R style inserts. Verify holder compatibility using the ISO code FLRP-3062R and insert size code 3062 before installation.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician with the machine powered down and spindle locked before seating or removing inserts. Use the appropriate torx or hex key specified by the toolholder manufacturer to secure the clamping mechanism; do not overtighten. Inspect the insert pocket and clamping surfaces for debris or wear before seating a new insert. Follow the machine tool builder and tooling manufacturer guidelines for speeds and feeds when setting up the first pass.
