Product Description
The TITAN PRO TRCF55 motor run capacitor is designed for car audio amplifier installation. This capacitor features a capacitance of 55 Microfarad and is designed to handle operating voltages up to 440 Volts. It is constructed with a round shape and aluminum case material.
- Capacitance of 55 Microfarad
- Maximum Voltage of 440 Volts
- Operating temperature range of -40 Degrees to 70 Degrees C
Product Highlights
The TRCF55 motor run capacitor is suitable for use with electric motors and is UL Recognized.
Product Information
Standard Information
-
Brand: TITAN PRO
-
Manufacturer Part Number: TRCF55
-
Country of Origin: China
Technical Specifications
-
Shape: Round
-
Capacitance: 55 Microfarad
-
Maximum Voltage: 440 Volts
-
Operating Voltage: 440 Volts
-
Item Model Number: TRCF55
-
Item: Motor Run Capacitor
-
Microfarad Rating: 55
-
Voltage: 440/370V AC
-
Frequency: 60/50 Hz
-
Diameter: 1.97" (50.038mm)
-
Case Height: 4-3/4 in.
-
Overall Height: 5 7/16 in
-
Overall Width: 2 in.
-
Overall Depth: 2 in.
-
EIA UL Base: A
-
Terminal Type: 1/4 In. Male Quick-Connect
-
Temperature Range: -40 Degrees to 70 Degrees C
-
Case Material: Aluminum
-
Cover Material: Steel
-
Standards: UL Recognized (E185318)
-
Brand: TITAN PRO
-
Product Type: Capacitor
-
MFD: 55
-
Height (Inches): 4.92"
-
Width (Inches): 1.97"
-
Model Number: TRCF55
-
Manufacturer: Packard
-
For Use With: Electric Motors
-
Connection Type: Quick Connect
-
Terminal Gender: Male
-
Max. Temperature: 70 Degrees C
-
Min. Temperature: -40 Degrees C
-
Number of Pieces: 1
-
Capacitor Voltage: 440/370V AC
-
EIA Tolerance Code: A
-
Terminal Tab Width: 1/4 in
-
Number of Terminals: 2
-
Motor Capacitor Type: Motor Run Capacitor
-
Terminal Designations: Standard
-
Capacitor Voltage Group: 440V AC
-
Capacitor Voltage (Merch): 440V AC
-
Country of Origin (subject to change): China
-
Operational Life: 60,000 hours
-
Height: 4.92" (124.968mm)
-
Can/Case: Round
-
Direct Replacement For: Packard: 325P556H44P36N4X, Industry Number: 12226, Industry Number: 12252, Industry Number: 12726, Industry Number: 12752, Supco: CR55X440R, Global: 2267, Smart Electric: SE5540DV, NTE: MRRC440V55, MRRC370V55
