Timken Co. 473010 473010 Dual Lip with One Spring

Product Description

The Timken Co. 473010 is a dual lip shaft seal designed for reliable sealing in a variety of applications. This model features a nitrile material construction, which enhances durability and resistance to wear. With precise specifications, it is ideal for general purpose use where effective sealing is paramount.

• 1.625 shaft diameter
• 2.502 housing bore diameter
• Requires a pressure of 7 psi

Product Highlights

This seal is well-suited for various industrial applications. The bonded design allows it to perform effectively under diverse conditions, maintaining a strong barrier against contaminants and fluids.

Product Information

Standard Information

• Brand: Timken Co.
• Part Number: 100754531

Technical Specifications

• Seal Application: General Purpose
• Case Construction: Steel Case w/o Inner Case
• Spring Material: Carbon Steel Garter
• Lip Style: Internal
• Lip Material: Nitrile
• Temperature Range [Min]: -40 °F
• Temperature Range [Max]: 225 °F
• Shaft Diameter: 1.625 in
• Housing Bore Diameter: 2.502 in
• Misalignment & Runout: 0.015@800, 0.010@4200
• Weight: 0.067 LB
• EAN or UPC: 53893493763
