THOMAS & BETTS 54134 Color-Keyed Compression Lug

Product Description

The THOMAS & BETTS 54134 is a non-insulated, one-hole compression lug crafted for copper conductors. This lug is made of copper and features a tin and nickel plating. It is designed to work with a six AWG conductor and fits a #10 stud. The lug includes a straight tongue, a standard barrel, and an inspection hole to verify conductor placement.

• Accommodates 6 AWG conductors.
• Includes a straight tongue and standard barrel.
• Rated for voltage applications from 600 VAC to 35 kV.

Product Highlights

Designed for reliability in electrical applications, this compression lug is essential for ensuring secure connections in various installations.

Product Information

Standard Information

• Brand: THOMAS & BETTS
• MPN: 54134

Technical Specifications

• Series: 54100
• Type: 1-Hole Non-Insulated
• Conductor Type: Copper
• Conductor Size: 6 AWG
• Voltage Rating: 600 VAC to 35 kV
• Stud Size: #10
• Tongue Type: Straight
• Overall Length: 1.23 inches
• Tongue Size: 0.53 inches L x 0.44 inches W x 0.07 inches THK
• Barrel Type: Straight Short Barrel
• Barrel Size: 0.31 inches Dia
• Mounting Hole Size: 0.204 inches
• Material: Copper
• Plating: Tin Plated, Nickel Plated
• Color: Blue
• Die Code: 24
• Die Color: BLUE
• Hole Quantity: 1
