Thomas Betts 17065-BD Ring Terminal 2/0 Awg

Product Description

The THOMAS BETTS 17065-BD is a 2/0 AWG ring terminal designed for high-current electrical connections in commercial and industrial wiring applications. It features a copper contact with a titanium nitride (TiN) plating, which improves corrosion resistance and provides a reliable mechanical connection under sustained load. This terminal is used to terminate large-gauge conductors at bus bars, lugs, switchgear, and heavy-duty equipment. Licensed electricians and industrial maintenance technicians are the primary installers of this type of lug connector.

This ring terminal is suited for applications requiring secure, low-resistance terminations on 2/0 AWG conductors. Typical use cases include power distribution panels, motor control centers, generator connections, and large HVAC equipment power feeds. The copper contact material and TiN plating make it appropriate for both copper and compatible conductor terminations in demanding electrical environments.

Key Features

• Copper contact material for excellent conductivity and reliable mechanical termination
• Titanium nitride (TiN) plating for added corrosion resistance
• Rated for 2/0 AWG wire, suitable for high-current applications
• Ring-style tongue provides secure bolt-down connection at lugs, bus bars, and studs
• Sold individually; minimum order quantity is 5 units

Compatibility

Designed as an OEM-style ring terminal for use with 2/0 AWG conductors in standard electrical termination applications where a copper, TiN-plated lug is specified.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the circuit before terminating or inspecting any connections. Use a calibrated crimping tool rated for 2/0 AWG terminals to ensure a proper mechanical and electrical crimp. Do not use a hammer or uncalibrated tool, as an improper crimp can cause resistance heating and connection failure over time.
