Telemecanique 9013FSG2J21 Water Pump Pressure Switch 575 VAC DPST 30 to 50 PSIG

Product Description

The Telemecanique 9013FSG2J21 is a water pump pressure switch designed for controlling electrically driven water pumps across various applications. This model supports jets, submersible pumps, and reciprocating types. It features diaphragm actuation and comes with adjustable differential settings for precise pressure control.

• UL Listed and CSA certified for commercial control equipment.
• Robust construction ensures durability and long service life.
• Equipped with screw clamp terminals for easy installation.

Product Highlights

This pressure switch provides reliable regulation between set pressure thresholds, essential for various pumping systems including agricultural irrigation and industrial applications.

Product Information

Standard Information

• Brand: Telemecanique
• Manufacturer: Telemecanique Sensors

Technical Specifications

• Catalog Number: 9013FSG2J21
• Operating Temperature: -33 to 257 degrees F
• Depth: 3.76 inches
• Width: 2.78 inches
• Height: 2.8 inches
• Weight: 1 lb
• Material: Noryl
• Electrical Contact Form: DPST
• Operating Cycles: 10 cycles/min
• Pressure Range: 5 to 65 psi
• Adjustment Range: 30 to 50 psi
