TECO XP7/54 Explosion Proof Electric Motor

Product Description

The TECO XP7/54 is a three-phase electric motor designed for hazardous environments. It features a totally enclosed fan cooled (TEFC) design that meets NEMA Premium efficiency standards. This electric motor is perfect for use in grain elevators, pumps, and blowers. Built with a durable cast iron frame and a stainless steel nameplate, it ensures reliability in challenging conditions.

• Explosion-proof design for Class I, Div. 1, Group C & D and Class II, Groups E, F, and G environments.
• Operates at 1800 RPM with a power output of 7.5 horsepower.
• Can be used in inverter duty applications for enhanced versatility.

Product Highlights

The TECO XP7/54 is built for bi-directional rotation and offers a service factor of 1.15, making it effective for continuous usage.

Product Information

Standard Information

• Brand: TECO
• Manufacturer Part Number: XP7/54

Technical Specifications

• Motor Type: TEFC, Explosion Proof
• Horsepower: 7.5 hp
• RPM: 1800
• Frame: 213T
• Phase: Three Phase
• Input Voltage: 208/230/460V
• Enclosure: XPFC
• Mounting: Footed, C Face
