TECO EP0034 3 HP Electric Motor

Product Description

The TECO EP0034 is a three-phase electric motor ideal for severe duty applications. This motor has a robust construction that includes a cast iron frame along with end brackets and a fan cover designed for durability. It is suitable for inverter duty applications and operates effectively in ambient temperatures up to 40 degrees Celsius and elevations reaching 3300 feet. This electric motor is UL Recognized, CSA Approved, and CE Marked.

• Three-phase operation at 60 Hz
• Cast iron frame for durability
• Designed for inverter duty applications

Product Highlights

The TECO EP0034 is built to perform under tough conditions, making it a reliable choice for various industrial applications.

Product Information

Standard Information

• Brand: TECO
• MPN: EP0034

Technical Specifications

• Horsepower: 3 hp
• RPM: 1800
• Voltage: 230/460VAC
• Frame Size: 182T
• Enclosure Type: TEFC
• Phase: Three Phase
• Operating Frequency: 60 Hz
• Insulation Class: Class F
• Ambient Temperature: 40 degrees C
• Elevation: 3300 ft
• Service Factor: 1.15 (Continuous); 1.0 @ 50 Hz
• Mounting Type: Footed (Rigid Base)
• Ingress Protection: IP54
• Design: NEMA Design B
