Product Description
The Techniks 04547-3/4 is an ER40 3/4 inch steel sealed collet. It is designed for precision clamping in various machining applications. This collet is suitable for use with different collet chuck series
- Clamping range up to three-fourths inches (19.05 mm)
- Maximum coolant pressure of two thousand PSI
- Accuracy with TIR of 0.0002 inches
Product Highlights
This collet provides a robust solution for high-pressure coolant applications, ensuring longevity and reliability.
Product Information
Standard Information
-
Brand: Techniks
-
Collet Series: ER40
Technical Specifications
-
Size: 3/4 inches (19.050 mm)
-
Clamping Range: 0.75 inches (19.05 mm)
-
Accuracy TIR: 0.0002 inches
-
Max Coolant PSI: 2000
-
Body Diameter: 1.61 inches
-
Head Diameter: 1.61 inches
-
Overall Length: 1.81 inches
-
Clamping Hole Length: 1.81 inches
-
Suitable For Use With: ER, RD, DR, ESX and BR Series Standard Collet Chuck
