Techniks 04546-3/4 TECH ER32 3/4 Steel Sealed Collet .0004 TIR No Collapse

Product Description

The Techniks 04546-3/4 is an ER32 steel sealed collet designed for precise tool holding. This collet features a clamping range of three-fourths of an inch and is engineered for high-pressure coolant applications. The accuracy is specified at 0.0002 inches TIR, ensuring tight tolerances for machining tasks.

• Max coolant pressure capacity of 2000 psi
• Compatible with ER, RD, DR, ESX, and BR series collet chucks
• Heat-treated for increased flexibility and longevity

Product Highlights

This collet provides excellent sealing capability, preventing coolant from leaking and protecting the tool holder from contaminants.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: ER32

Technical Specifications

• Size: 3/4 inch (19.050 mm)
• Clamping Range: 0.75 inch (19.05 mm)
• Accuracy TIR: 0.0002 inches
• Max Coolant PSI: 2000
• Body Diameter: 1.3 inches
• Head Diameter: 1.3 inches
• Overall Length: 1.575 inches
• Clamping Hole Length: 1.575 inches
