Techniks 04010-7/16 TECH TG100 7/16 Collet

Product Description

The Techniks 04010-7/16 is a TECH TG100 7/16 collet designed for precision toolholding applications. This collet supports a clamping range from zero point four two two zero inches to zero point four three eight zero inches. Ideal for use in conjunction with TG collet chucks, it provides an accuracy of zero point zero zero zero four inches TIR.

• Clamping range: 0.4220 - 0.4380 inches
• Accuracy TIR: 0.0004 inches
• Compatible with TG Collet Chuck

Product Highlights

This collet offers high precision and reliable performance for various machining tasks.

Product Information

Standard Information

• Brand: Techniks
• MPN: 04010-7/16

Technical Specifications

• Collet Series: TG100
• Size: 7/16 inches (11.113 mm)
• Clamping Range: 0.4220 - 0.4380 inches (10.716 - 11.113 mm)
• Accuracy TIR: 0.0004 inches
• Overall Length: 3 inches
• Clamping Hole Length: 2-3/8 inches
• Body Diameter: 2.001 inches
• Head Diameter: 2.001 inches
