Techniks 04010-5/16 TECH TG100 5/16 COLLET

Product Description

The Techniks 04010-5/16 is a precision collet part of the TG100 series. It measures five-sixteenths of an inch, which is approximately seven point nine three eight millimeters. This collet is designed for a clamping range from zero point two nine seven zero inches to zero point three one three zero inches, effectively encompassing diameters between seven point five four one and seven point nine three eight millimeters. The total indicated runout (TIR) for accuracy is zero point zero zero zero four inches, suitable for aligning tooling and maintaining precision during machining operations.

• Clamping Range: 0.2970 - 0.3130 in (7.541 - 7.938 mm)
• Accuracy TIR: 0.0004 inches
• Size: 5/16 (7.938 mm)

Product Highlights

This collet is ideal for applications requiring high precision. It is commonly used with TG collet chucks ensuring stability and accuracy.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: TG100

Technical Specifications

• Size: 5/16 (7.938 mm)
• Clamping Range: 0.2970 - 0.3130 (7.541 - 7.938)
• Accuracy TIR: 0.0004
