Techniks 04010-3/16 TECH TG100 3/16 Collet

Product Description

The Techniks 04010-3/16 is a standard collet from the TG100 series designed for precision toolholding. This collet has a size of three-sixteenths of an inch, which is equivalent to four point seven six three millimeters. It offers a clamping range between zero point one seven two zero and zero point one eight eight zero inches, suitable for various applications.

• Clamping range allows for a secure grip on a range of tool sizes
• Accuracy TIR of zero point zero zero zero four inches ensures precise operation
• Compatible with TG collet chucks for streamlined performance

Product Highlights

This collet provides high accuracy and reliability for machining tasks. It is designed to fit standard setups and meets industrial needs.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: TG100

Technical Specifications

• Size: 3/16 inches (4.763 mm)
• Clamping Range: 0.1720 - 0.1880 inches (4.366 - 4.763 mm)
• Accuracy TIR: 0.0004 inches
• Body Diameter: 2.001 inches
• Head Diameter: 2.001 inches
• Overall Length: 3 inches
• Clamping Hole Length: 2-3/8 inches
• Suitable For Use With: TG Collet Chuck
