Tech Products 52522 Leveling Mount 3/8-16 170 Lb

Product Description

The TECH PRODUCTS 52522 is a standard deflection leveling mount designed to isolate vibration and provide stable, adjustable support for mechanical equipment. Built with a steel stud and neoprene pad, it absorbs vibration at the base of units such as compressors, fans, pumps, and HVAC equipment. The 3/8-16 threaded stud handles up to 170 lb of load capacity per mount, making it a practical choice for light-to-medium commercial and residential mechanical installations. Maximum deflection is 0.25 inches, providing consistent isolation performance across the load range. HVAC technicians, millwrights, and mechanical contractors install these mounts during equipment setting and commissioning.

This leveling mount is suited for use under rooftop units, condensing units, air handlers, pumps, and similar mechanical equipment where vibration isolation and height adjustment are needed. The neoprene pad provides surface grip and vibration dampening, while the steel stud allows for height adjustment and secure fastening to a base frame or equipment foot. Typical applications include both commercial rooftop installations and residential mechanical room settings where equipment must be leveled on uneven surfaces.

Key Features

• 170 lb load capacity per mount for light-to-medium mechanical equipment support
• 3/8-16 threaded steel stud for secure attachment and height adjustment
• Neoprene pad provides vibration isolation and surface grip
• Maximum deflection of 0.25 inches for consistent isolation performance
• 1.75 inch base diameter with 11/32 inch mounting hole diameter for straightforward anchoring
• Overall width of 2.375 inches and overall height of 1.25 inches for compact fitment

Compatibility

Designed as a standard-deflection leveling mount for use with residential and light commercial mechanical equipment requiring 3/8-16 threaded vibration-isolation mounting points.

Installation Notes

Installation is typically performed by HVAC technicians or mechanical contractors during equipment placement and commissioning. De-energize all equipment before positioning mounts under unit feet. Ensure mounting surfaces are clean and flat before seating the neoprene pad. Distribute load evenly across all mount points and verify equipment level before final stud tightening.
