Sugatsune HG-OTB75 Quick Release Hinge Stainless Steel

Product Description

The SUGATSUNE HG-OTB75 is a quick release hinge manufactured from stainless steel with a polished finish. It is designed for applications where panels, doors, or access covers must be removed quickly without tools. The hinge features a removable pin mechanism that allows the two leaves to separate instantly, making it well suited for maintenance-heavy installations. At 1-31/32 inches wide and 1/16 inch thick per leaf, this is a compact hinge intended for light-duty assemblies. The 1/4-inch pin diameter provides a secure pivot point during normal operation while still permitting fast disassembly when needed. Licensed tradespeople and fabricators working with enclosures, equipment panels, or cabinetry will find this hinge practical where frequent access is required.

This hinge is used in applications where removable hinged panels are part of the design, such as electrical enclosures, HVAC service access doors, marine cabinetry, food service equipment, and industrial control panels. The polished stainless steel construction suits environments where corrosion resistance and a clean appearance are both required. It is appropriate for both commercial and light industrial settings. The compact leaf dimensions allow installation in tight clearance areas where a standard fixed-pin hinge would impede panel removal.

Key Features

• Quick release pin design allows tool-free panel or door removal
• Stainless steel construction provides corrosion resistance for demanding environments
• Polished finish suits applications where surface appearance matters
• Compact 1-31/32 inch width fits tight clearance installations
• 1/4-inch pin diameter delivers a stable pivot under normal load
• Low profile 1/16-inch leaf thickness minimizes protrusion at the hinge line

Compatibility

Designed as an OEM-style or aftermarket quick release hinge for light-duty panel, door, and access cover assemblies requiring tool-free removal in commercial and industrial applications.

Installation Notes

Installation is typically performed by a millwright, cabinet fabricator, or maintenance technician. Secure both leaves with appropriate fasteners for the substrate material before testing pin release and re-engagement. Verify that the mating panel aligns correctly with the pin fully seated before returning the assembly to service. Follow applicable OSHA lockout-tagout procedures when installing on electrical enclosures or powered equipment.
