Product Description
The SteelCrest BTU30X20RWHH is a fixed-blade return air grille designed for wall and ceiling installations in residential and light commercial HVAC systems. Constructed from solid steel with a white powder-coat finish, it provides a durable, corrosion-resistant surface suited for long-term use. The slotted fixed-blade design supports consistent return airflow back to the air handler or furnace without the adjustability of a register. It fits a 30 x 20 inch duct opening and installs with an overall finished face size of 32 x 22 inches, covering the rough opening cleanly. HVAC technicians and contractors install this grille during new construction, system retrofits, or cosmetic upgrades.
This grille is appropriate for residential and light commercial applications where a clean, fixed return air opening is required at a wall or ceiling surface. The 30 x 20 inch duct opening size is commonly found in central ducted systems serving larger zones or whole-home return air paths. The finished 32 x 22 inch face overlaps the duct opening perimeter, eliminating visible gaps at the drywall or ceiling surface. It suits new construction framing as well as remodel work where the existing duct rough-in matches the 30 x 20 opening dimension.
Key Features
- Solid steel construction with white powder-coat finish for durability and clean appearance
- Fixed slotted blade design promotes consistent, unobstructed return airflow
- Fits 30 x 20 inch duct opening with a 32 x 22 inch overall finished face size
- Suitable for wall or ceiling mounting in ducted HVAC systems
- Direct-replacement sizing speeds installation in new construction and remodel projects
Compatibility
Designed as a direct-replacement fixed return air grille for ducted HVAC systems with a 30 x 20 inch rough-in duct opening on walls or ceilings.
Installation Notes
Installation is typically performed by a licensed HVAC technician or qualified contractor. Turn off the HVAC system at the thermostat and disconnect power at the air handler before beginning work. The grille face mounts over the duct opening using the perimeter flange; verify the rough-in opening measures 30 x 20 inches before installation. This is a fixed return grille with no movable blades, so no damper adjustment is required after mounting.
Technical Specifications
-
Duct Opening Size: 30 x 20 inches
-
Overall Finished Face Size: 32 x 22 inches
-
Blade Type: Fixed slotted
-
Material: Solid steel
-
Finish: White powder coat
-
Mount Location: Wall or ceiling
-
Application: Return air
-
Package Weight: 33 pounds
-
Package Dimensions: 35 x 25 x 3 inches
-
Minimum Order Quantity: 1
Standard Information
-
Brand: SteelCrest
-
Manufacturer Part Number: BTU30X20RWHH
