Square D ZBY2313 Rectangular Legend Plate Open 30mm

Product Description

The SQUARE D ZBY2313 is a rectangular legend plate designed for use with 30mm selector switches in industrial and commercial control panel applications. Marked with the word "Open" in white letters on a black and red background, this plate provides clear operator identification at a glance. It measures 1.18 inches wide by 1.57 inches high with a lettering height of approximately 0.31 inches. Electricians and control panel builders use legend plates like this to label switch positions, improving safety and panel readability. The plate is a direct-mount accessory requiring no special tools for installation.

This legend plate is suited for use on 30mm selector switches in machine control panels, motor control centers, and industrial automation enclosures. It fits residential, light commercial, and heavy industrial environments wherever clear switch labeling is required. The Open designation makes it appropriate for circuits where operators must identify the de-energized or open-circuit switch position at a glance.

Key Features

• White "Open" lettering on black and red background for high-contrast readability
• Rectangular form factor sized for 30mm selector switch cutouts
• Overall dimensions of 1.18 inches wide by 1.57 inches high
• Lettering height of 8mm for clear, legible switch position identification
• Lightweight construction at 0.01 pounds for easy panel integration

Compatibility

Designed for use with 30mm selector switches as stated by the manufacturer. Verify specific switch model fitment before installation.

Installation Notes

Legend plates of this type are installed by electricians during control panel assembly or maintenance. Disconnect and lock out all power to the panel before servicing any control components. The plate typically snaps or slides into position on the switch operator without additional tools. Follow applicable NEC guidelines for industrial control panel labeling and component installation.
