Square D QOB360VH Miniature Circuit Breaker 60A 240V 3Ph , Bolt-On

Product Description

The Square D QOB360VH is a miniature circuit breaker designed for overcurrent protection in AC and DC systems. With a three-pole configuration rated for sixty amps at two hundred forty volts, this bolt-on circuit breaker features a trip-free toggle mechanism for reliable performance.

• Three-pole design with sixty amp capacity
• Visual trip indication with VisiTrip feature
• Compatible with various factory-installed accessories

Product Highlights

This circuit breaker offers a breaking capacity of twenty-two kiloamperes, ensuring it can handle significant overloads. The compact design of three-quarter inches helps to optimize space in electrical panels, making it ideal for small installations.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QOB360VH
• Type: Miniature circuit-breaker
• Number of Poles: 3
• Current Rating: 60 Amps
• Voltage Rating: 240 Volts AC
• Interrupt Rating: 22 kAIC
• Dimensions: Length - two point nine one inches, Width - fifty-seven mm, Height - seventy-nine mm
• Country of Origin: Mexico
