Square D QOB340 Miniature Circuit Breaker 40A 240V 3Ph Bolt-On

Product Description

The Square D QOB340 miniature circuit breaker is designed for reliable overcurrent protection in three-phase systems. This model features a current rating of 40 amps at 240 volts AC. It is a bolt-on circuit breaker, providing easy installation in panelboards, specifically the NQ series. The innovative design includes a quick-make, quick-break toggle mechanism that ensures prompt tripping during overload conditions. The VisiTrip indicator visually alerts users when the breaker has tripped, enhancing system safety.

• Three-pole configuration for three-phase circuits
• Rated 40A at 240VAC with ten kA breaking capacity
• Compatible with shunt trips and auxiliary switches

Product Highlights

This circuit breaker meets UL and CSA standards, ensuring high reliability and performance in various applications including lighting and appliances.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QOB340
• Type: Miniature circuit-breaker
• Current Rating: 40A
• Voltage Rating: 240VAC
• Number of Poles: 3
• Mounting Type: Bolt-on
• Interrupting Rating: 10 kA
• Country of Origin: Mexico
• Warranty Length: 18 months
