Square D QO142L225PGC QO Load Center 1 Phase 225A

Product Description

The SQUARE D QO142L225PGC is a QO load center that offers premium features, allowing QO breakers, ground fault interrupters, arc fault interrupters, and surge arresters to be installed inside. Designed for residential and industrial use, it protects electrical systems, equipment, and people. This 1 phase load center has 42 spaces and 52 circuits with 225A convertible main lugs in a NEMA 1 enclosure. It includes plug on neutral, ground bar, combination cover, and is UL rated.

• Allows QO breakers, ground fault interrupters, arc fault interrupters, and surge arresters to be installed inside
• Designed for residential and industrial use
• Protects electrical systems, equipment, and people
• Tin plated copper bus bars

Product Highlights

This Square D QO load center is suitable for residential and industrial applications, offering protection and convenience with its array of features and accessories.

Product Information

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: QO142L225PGC
• Country of Origin: United States

Technical Specifications

• Catalog Number: QO142L225PGC
• Manufacturer: Schneider Electric
• Brand: Square D
• Country of Origin: United States
• Made in USA: Yes
• Cable Size: AWG 6...300 kcmil aluminium/copper
• Cover Type: Combination flush/surface cover
• Enclosure: Baked enamel Gray;Welded sheet steel;11
• Phase: 1
• Special Features: Tin plated copper: busbar
• Item Type: Load Center
• Type: Main Breaker, Convertible
• Voltage Rating: 120/240 Volt AC
• Circuit Configuration: 1-Phase
• Maximum Number of Spaces: 42
• Breaker Mounting: Plug-On
• Interrupting Rating: 22 Kiloamp
• Enclosure Type: NEMA 1
• Approval: UL
• RoHS Compliant: Yes
• Ambient Air Temperature: 23 to 104 Deg F (Operation)
