Square D QO140M200PC Load Center 200A 1 Phase 40 Spaces

Product Description

The Square D QO140M200PC is a reliable load center designed for residential and industrial applications. This product offers features that accommodate various breakers, ground fault interrupters, arc fault interrupters, and surge arresters.

• Supports plug-on neutral configurations
• 200 Amp convertible main breaker
• Designed for safety and efficiency

Product Highlights

This load center includes a NEMA 1 enclosure and is UL listed for safety standards. It has 40 spaces and 60 circuits, making it suitable for various electrical installations.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QO140M200PC
• Current Rating: 200 Amp
• Number of Phases: 1 Phase
• Number of Spaces: 40
• Number of Circuits: 60
• Cover Type: Combination flush/surface cover
• Dimensions: Width 362 mm, Height 858 mm, Depth 95 mm
• Net Weight: 15.250 kg
• Short-Circuit Current: 22 kA
• Operating Temperature: -5 °C to 40 °C
