Square D HGL26015 Molded Case Circuit Breaker 15A 2 Pole

Product Description

The SQUARE D HGL26015 is a 2-pole molded case circuit breaker rated for 15 amps, 600 VAC, and 250 VDC. It uses a thermal-magnetic trip mechanism to provide overload and short-circuit protection in commercial and industrial power distribution panels. Lug-style terminal connections accept wire sizes from 14 to 3/0 AWG, giving installers flexibility across a wide range of conductor sizes. The multiple breaking capacity ratings make this breaker suitable for applications where available fault current levels vary. Electricians and panel technicians install this breaker as both a new installation component and a direct replacement in existing switchgear.

This breaker is designed for panel-mount installation in commercial, industrial, and heavy-duty residential power distribution equipment. It is commonly installed in load centers, switchboards, and motor control panels where 600 VAC two-pole overcurrent protection is required. The wide wire range and lug terminals support both feeder and branch circuit applications. Its compact molded case housing is suited for high-density panel environments where space and reliable fault interruption both matter.

Key Features

• Thermal-magnetic trip mechanism provides both overload and short-circuit protection
• Rated 15 amps, 600 VAC and 250 VDC for broad application coverage
• 2-pole configuration for single-phase or DC circuit protection
• Lug terminal connections accept 14 to 3/0 AWG conductors
• Multiple breaking capacity ratings for variable fault current environments
• Certified to CE, CSA, IEC, and UL Listed standards

Compatibility

Designed as an OEM-style replacement or new-installation molded case circuit breaker for commercial and industrial panel-mount applications requiring 2-pole, 600 VAC overcurrent protection.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before mounting or wiring this breaker. Verify that conductor size and type are within the 14 to 3/0 AWG lug rating before terminating. Do not exceed the breaker's voltage or amperage ratings for the intended circuit.
