Square D HDL36035 Molded Case Circuit Breaker 35A 3P

Product Description

The SQUARE D HDL36035 is a 3-pole molded case circuit breaker rated for 35 amps at 600 VAC and 250 VDC. It uses a thermal-magnetic trip mechanism to provide both overload and short-circuit protection in a single device. The breaker mounts directly to a panel and accepts wire sizes from 14 AWG up to 3/0 AWG via lug-style terminal connections. It carries multiple breaking capacity ratings, making it suitable for applications where fault current levels vary. Licensed electricians install this breaker during new construction, panel upgrades, and equipment branch circuit work in commercial and industrial settings.

This circuit breaker is suited for commercial and light industrial power distribution panels where a 3-pole, 600 VAC-rated device is required. Typical applications include branch circuit protection for three-phase motor loads, HVAC equipment, and general electrical distribution in commercial buildings. The wide wire range of 14 to 3/0 AWG allows use across a broad range of conductor sizes encountered in panel and switchgear installations.

Key Features

• 35-amp continuous rating at 600 VAC and 250 VDC
• 3-pole configuration for three-phase circuit protection
• Thermal-magnetic trip for overload and short-circuit protection
• Lug-style terminals accept 14 AWG to 3/0 AWG conductors
• Panel mount design for direct installation in distribution equipment
• Multiple breaking capacity ratings for varied fault current environments
• Certified to CE, CSA, IEC, and UL standards

Compatibility

Designed as an OEM-style replacement molded case circuit breaker for commercial and industrial panel and switchgear assemblies requiring a 3-pole, 35-amp, 600 VAC thermal-magnetic device with lug terminations.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing any circuit breaker. Verify that conductor sizes fall within the 14 AWG to 3/0 AWG lug range and that torque is applied per the lug manufacturer specifications printed on the device label. Confirm that the available fault current at the installation point does not exceed the breaker breaking capacity rating selected for that application.
