The Square D EDB24025 is an E-Frame miniature circuit breaker designed for use in Square D NF Panelboards. This 2-pole, 25A circuit breaker offers superior overload and short circuit protection. It features a thermal-magnetic trip unit and a signal indicator. The EDB24025 is UL Listed as High Intensity Discharge and HACR rated.

  • E-Frame Breaker
  • Thermal-magnetic trip unit
  • UL Listed as High Intensity Discharge

Product Highlights

Provides overload and short circuit protection. Features a thermal-magnetic trip unit and signal indicator. Suitable for Square D NF Panelboards.

Product Information

Standard Information

  • Brand: SQUARE D
  • Manufacturer Part Number: EDB24025
  • Country of Origin: Ireland
Technical Specifications
Type
Miniature circuit-breaker
Brand
Square D
Depth
4.05 Inch
Frame
E-FRAME
Width
1.96 in
Height
5.66 Inch
Length
4.05 Inch
Voltage
277/480 VAC
Amperage
25 Amp
Sub Brand
EDB
Trip Type
Thermal-magnetic
Net Weight
3 lb
Trip Range
875 A
Module Type
E-Frame
Product UPC
78590131101
12-Digit UPC
785901311010
Applications
HACR rated;HID rated
Mounting Type
Bolt-On
TC Connection
AWG 12...AWG 6 ALUMINIUM-AWG 14...AWG 6 COPPER,LUGS ALUMINIUM
Certifications
CULus
Number of Poles
2 Pole
Interrupt Rating
18, 25 kAIC
Number of Spaces
2
Country of Origin
Mexico
Line Rated Current
25 A
Catalog Number
EDB24025
Manufacturer
Schneider Electric
UPC
785901311010
GTIN
00785901311010
Voltage Rating
120/240/277 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA), 240 VAC at 50/60 Hz (IEC)
Current Rating
25 Ampere
Interrupting Rating
25 Kiloampere at 120/240 VAC, 18 Kiloampere at 480 VAC Star/277 VAC or 277 VAC (UL/CSA)
Trip Setting
270 to 875 Ampere
Installation
Bolt-On
Application
Lighting
Used On
Class 515 NF Series Panelboard
Approval
UL, CSA, NOM 117
Frame Type
E
Size
1.96 Inch W x 4.05 Inch D x 5.66 Inch H
Tripping Method
Thermal Magnetic
Terminal Wire Size
12 to 6 AWG (Aluminum), 14 to 6 AWG (Copper)
Product Group
BISS
Product Type
CIRCUIT_BREAKER
Number of Items
1
Range Of Product
125 A Frame EDB-EGB-EJB
Trip Unit Rating
875-875 A
Product Or Component Type
miniature circuit-breaker
Device Short Name
EDB
Holding Current
270 A
Tightening Torque
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Breaking Capacity Code
D
Product Destination
NF panelboard
Electrical Connection
Aluminum Lugs
Number Of Spaces Required
2
Protection Type
short-circuit || overload
Local Signalling
trip indicator
Awg Gauge
AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
Breaking Capacity
18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
Trip Unit Technology
thermal-magnetic
[Ue] Rated Operational Voltage
480Y/277 V AC
Product Certifications
cULus
Ambient Air Temperature For Operation
40 °C
Part Number
EDB24025
Family
EDB Series
Pole
2
Amp
25
Volt
480
Phase
1
Category
Molded Case / 2-Pole
Connection
Bolt-On
Functions
LI - Long-Time and Instantaneous
Protection
Thermal Magnetic
AIC Ratings
18kA@480V | 18kA@277V | 25kA@240V | 25kA@120V
Dimensions (HxWxD)
5.66" x 1.96" x 4.05"
Maximum Operating Voltage
480Y/277 V AC
Mounting Mode
Bolt-On
Wire Size
12 to 6 AWG, 14 to 6 AWG, 14 to 6 AWG AL, 12 to 6 AWG Cu
UNSPSC
39121603
