Square D 9998DA2V06 Contactor Replacement Coil

Product Description

The SQUARE D 9998DA2V06 is a replacement contactor coil designed for use with 8910DPA series contactors. The coil is the electromagnetic component that energizes the contactor, pulling in the armature to close the power contacts when a control signal is applied. This part is a direct accessory replacement, restoring proper contactor operation when the original coil has failed due to burnout or physical damage. It measures 1.8 inches in length, 3.5 inches in width, and 2.6 inches in height, and weighs 0.14 pounds. Licensed electricians and HVAC technicians performing electrical panel or motor control circuit service are the primary installers of this component.

This coil is intended for use in contactor applications where the 8910DPA series contactor is installed. The 8910DPA line is commonly found in motor control, lighting, and HVAC load-switching applications across residential and light commercial installations. When a contactor fails to pull in or the coil shows signs of overheating or open-circuit failure, replacing the coil with this OEM-style accessory restores full switching function without replacing the entire contactor body.

Key Features

• Direct replacement coil accessory for 8910DPA series contactors
• Restores contactor pull-in function after coil burnout or failure
• Compact form factor: 1.8 x 3.5 x 2.6 inches
• Lightweight at 0.14 pounds for easy handling during service
• Sold individually as a single-unit replacement component

Compatibility

Designed for use with SQUARE D 8910DPA series contactors as a replacement coil accessory.

Installation Notes

Installation should be performed by a licensed electrician or qualified HVAC technician. Always de-energize and lock out the electrical panel or disconnect serving the contactor before beginning coil replacement, following NFPA 70E arc flash and lockout/tagout procedures. Verify the control circuit voltage matches the coil rating before energizing. Refer to the 8910DPA contactor documentation for proper coil seating and retention procedures.
