Product Description
The Square D 9422AP1 is a handle mechanism with a 6 inch handle depth for NEMA 1/3/3R/4/12 enclosures. It is designed for use with 9422RM1, 9422CMP, and PowerPacT M and P operating mechanisms. This handle mechanism offers field installable accessories and complies with UL standards.
- 6 inch handle depth
- For NEMA 1/3/3R/4/12 enclosures
- For use with 9422RM1, 9422CMP, and PowerPacT M and P operating mechanisms
Product Highlights
This Square D handle mechanism is suitable for use with disconnect switch and circuit breaker installations.
Product Information
Standard Information
-
Brand: SQUARE D
-
Manufacturer Part Number: 9422AP1
-
Country of Origin: Mexico
Technical Specifications
-
Size: 6 in
-
Type: Handle Mechanism
-
Brand: Square D
-
Length: 6 Inch
-
Actuator: 6 INCH HANDLE
-
Enclosure: NEMA 1/3/3R/4
-
Indicator: OFF/ON
-
Sub Brand: SCHNEIDER ELECTRIC
-
Product UPC: 78590183404
-
12-Digit UPC: 785901834045
-
Applications: NEMA 1/3/3R/4/12 enclosures;9422RM1 circuit breaker mechanism;9422CMP circuit breaker mechanism
-
TC Connection: FLANGE MOUNT
-
Manufacturer: Schneider Electric
-
Country of Origin: United States
-
Made in USA: Yes
-
Application: 9422RM1 circuit breaker mechanism;9422CMP circuit breaker mechanism; 9422CMP circuit breaker mechanism; 9422RM1 circuit breaker mechanism;NEMA 1/3/3R/4/12 enclosures
-
Special Features: Variable depth
-
UPC: 785901834045
-
GTIN: 00785901834045
-
Item Type: Handle Mechanism
-
Breaker Type: M/P Frame
-
Material: Sheet Steel
-
Used On: 9422RM1/9422CMP Circuit Breaker Mechanism, Cable Operated and Variable Depth Mechanism
-
Item [Specifications]: Operating Mechanism Handle
-
Length [Specifications]: 6 in
-
Product Destination [Specifications]: 9422RM1 circuit breaker mechanism || 9422CMP circuit breaker mechanism, 9422CMP circuit breaker mechanism || 9422RM1 circuit breaker mechanism
-
Product Compatibility [Specifications]: NEMA 1/3/3R/4/12 enclosures
-
Specificity Of Operator [Specifications]: variable depth
-
Product Or Component Type [Specifications]: Handle Mechanism
-
Country of Origin (subject to change) [Specifications]: Mexico
-
Alternate Catalog Number: 9422AP1
-
ARRA Compliant: N
-
Buy American Compliant: N
-
Connection: FLANGE MOUNT
-
Dimensions: 6 in L
-
Handle Mounting Position: Flange
-
Harmonization Tariff Schedule Code: 8538908180
-
Height: 4.5720 in
-
Mounting: Flange
-
NEMA Rating: NEMA 1/3/3R/4/12
-
Standard: NEMA
-
Suitable For Use With: 9422RM1, 9422CMP and 9422CSJD Disconnect Operating Mechanism
-
UNSPSC: 39122233
-
Model: 9422AP1
-
MPN: 9422AP1
-
Width: 9.6520 in
