Square D 9080GRL6 Din Rail Terminal Block 600V 60A

Product Description

The SQUARE D 9080GRL6 is a standard DIN rail mount terminal block rated for 600 VAC and 60 amps. It is designed for use in electrical enclosures and control panels where reliable wire termination is required. The block features 2 contacts made from copper, housed in a blue nylon body that withstands operating temperatures from -40 to 275 degrees F. It accepts wire sizes from 22 AWG to 8 AWG, making it suitable for a wide range of control and power wiring applications. Licensed electricians and panel builders typically specify this component during enclosure assembly or control panel fabrication.

The 9080GRL6 is suited for both commercial and industrial electrical installations where DIN rail mounted terminal blocks are the standard wiring method. Its single-row, 2-contact configuration fits panels with limited real estate. The nylon construction and copper contacts provide solid performance in environments subject to temperature swings. This block is commonly installed in motor control centers, distribution panels, and automation enclosures.

Key Features

• Rated 600 VAC and 60 amps for robust control and power circuit wiring
• 2 copper contacts in a single-row configuration
• Accepts 22 AWG to 8 AWG wire sizes
• Blue nylon block body rated from -40 to 275 degrees F
• DIN rail mount for fast, tool-assisted installation in standard enclosures
• CE Marked, CSA Certified (LR62144 Class 6228 01), UL Listed (E60616 CCN XCFR2), and RoHS Compliant

Compatibility

Designed as an OEM-style replacement or new-installation terminal block for standard DIN rail systems in electrical control panels and enclosures requiring 600 VAC rated terminations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the panel and verify zero voltage with a meter before handling any terminal blocks or conductors. Snap the block onto a standard DIN rail and confirm it is fully seated before making wire connections. Torque wire terminations per the enclosure or panel schedule specifications.
