Square D 9070SF25A Transformer Bracket Type T Tf

Product Description

The SQUARE D 9070SF25A is a transformer bracket designed for use with Type T and Type TF transformers. This mounting accessory provides a secure attachment point that keeps the transformer properly positioned within an electrical enclosure or panel assembly. Licensed electricians and industrial maintenance technicians install this bracket during new transformer installations or when replacing a damaged or missing mounting component. At 0.06 pounds, it is a lightweight piece that ships as a single unit. Its compact dimensions make it straightforward to handle in tight enclosure spaces.

This bracket is intended for use in commercial and industrial electrical installations where Square D Type T or Type TF transformers are deployed. It serves as a direct accessory replacement in panel boards, control enclosures, and similar assemblies where transformer mounting integrity is required. It is sold and packaged as a single unit.

Key Features

• Designed specifically for use with Square D Type T and Type TF transformers
• Compact profile: 3.1 inches long, 2.3 inches wide, 1.3 inches tall
• Lightweight at 0.06 pounds for easy handling during installation
• Single-unit packaging simplifies parts ordering for service calls
• Functions as a direct replacement accessory for existing transformer assemblies

Compatibility

Designed for use with Square D Type T and Type TF transformers as a mounting bracket accessory.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements. De-energize and lock out the circuit before removing or installing any transformer mounting hardware. Verify that all fasteners are fully seated and that the transformer is stable in the bracket before restoring power. Do not energize the transformer until the bracket and all associated hardware are confirmed secure.
