Square D 9070FB1A Fuse Block 1 Pole 120V Class T

Product Description

The SQUARE D 9070FB1A is a single-pole fuse block rated at 120 volts and designed to accept Class T fuses with a 0.25 inch diameter and 1.25 inch length. Fuse blocks provide a secure, serviceable point of overcurrent protection within a control panel, machine enclosure, or distribution assembly. This unit is CE Marked, CSA Certified, NOM Certified, and UL Listed, meeting the certification requirements common in commercial and industrial installations. Licensed electricians and panel builders use this component when constructing or servicing low-voltage control circuits and equipment protection assemblies.

The 9070FB1A is suited for single-phase, 120-volt branch circuits and control circuits where Class T fuse protection is specified. Typical applications include industrial control panels, HVAC equipment control sections, and motor control enclosures that require a compact, code-compliant fuse holder. Its small footprint makes it practical for tight panel layouts where space is limited.

Key Features

• Single-pole configuration rated at 120 volts
• Accepts Class T fuses at 0.25 inch diameter and 1.25 inch fuse length
• UL Listed, CSA Certified, CE Marked, and NOM Certified for broad compliance
• Compact body dimensions of 3.8 inches height, 4.2 inches width, and 4.2 inches length
• Sold as a single unit, suitable for individual replacement or panel build applications

Compatibility

Designed as an OEM-style replacement fuse block for single-pole, 120-volt control and branch circuit applications requiring Class T fuse holders in panel or enclosure assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the circuit before installing or servicing this fuse block. Verify that the fuse rating and class match the circuit protection requirements before inserting the fuse. Do not exceed the 120-volt voltage rating of this device.
