Square D 9007TYD5 Limit Switch Spdt Nc Rotary Head 600V

Product Description

The SQUARE D 9007TYD5 is a general purpose limit switch designed for industrial position-sensing and machine control applications. It features a single-pole double-throw (SPDT) contact form with a normally closed (NC) configuration and a rotary head actuator mounted on the side of the zinc-body enclosure. Rated for 600 volts AC, this switch delivers reliable switching performance in demanding environments. The screw terminal connection and robust zinc housing make it a practical choice for licensed electricians and industrial maintenance technicians working on automated machinery, conveyor systems, and process control equipment.

The 9007TYD5 is suited for both light industrial and heavy-duty applications where position detection, end-of-travel sensing, or door interlock functions are required. Its IP65, IP66, and IP67 ingress protection ratings allow installation in wet, dusty, or wash-down environments. NEMA ratings of 1, 2, 4, 12, and 13 confirm suitability for a wide range of indoor and select outdoor industrial enclosure conditions. Operating temperatures range from -10 degrees F to 185 degrees F, making it appropriate for use in heated process areas as well as unheated industrial spaces.

Key Features

• SPDT contact form with normally closed (NC) configuration for fail-safe position sensing
• Rotary head actuator with 12 degrees of travel, side-mounted for flexible installation
• 600 volt AC rating for compatibility with standard industrial control circuits
• IP65, IP66, and IP67 ingress protection for wet and wash-down environments
• NEMA 1, 2, 4, 12, and 13 rated enclosure for broad application coverage
• CE, CSA Certified, UL 508, and UL Listed for code compliance on commercial and industrial projects

Compatibility

Designed as an OEM-style replacement or new-installation limit switch for general purpose industrial machine control and position-sensing applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize the circuit and lock out and tag out all power sources before mounting or wiring the switch. Secure the switch body to a rigid mounting surface to ensure consistent actuator travel and reliable contact operation. Verify screw terminal torque is within the panel or equipment manufacturer guidelines before returning the circuit to service.
