Square D 9007TUD5 Limit Switch Spdt Nc Rotary Head 600V

Product Description

The SQUARE D 9007TUD5 is a general purpose limit switch designed for industrial machine control and position-sensing applications. It features a single-pole double-throw (SPDT) contact form with a normally closed (NC) configuration and a rotary head actuator mounted on the side of the body. The switch is rated for 600 volts AC and is housed in a zinc body that meets IP65, IP66, and IP67 ingress protection ratings. Screw terminals provide a secure, serviceable wiring connection. Licensed electricians and industrial maintenance technicians are the primary installers for this device.

The 9007TUD5 is suited for use in residential, commercial, and light industrial control panels, conveyor systems, machinery interlocks, and door or gate position sensing. The rotary head actuator operates from the side entry point, making it appropriate for tight enclosures or applications where the actuating mechanism approaches from a lateral direction. Its NEMA ratings of 1, 2, 4, 12, and 13 cover a broad range of indoor and outdoor environments, including protection against dust, oil, and coolant splash.

Key Features

• SPDT contact form with normally closed (NC) configuration for fail-safe circuit design
• Rotary head actuator with side mounting for lateral approach applications
• 600V AC voltage rating suitable for industrial control circuits
• Zinc body construction with IP65, IP66, and IP67 ingress protection
• NEMA 1, 2, 4, 12, and 13 ratings covering a wide range of installation environments
• Screw terminal connections for reliable field wiring
• CE marked, CSA Certified, and UL Listed to UL 508

Compatibility

Designed as an OEM-style replacement or new-installation limit switch for general purpose industrial machine control applications requiring an SPDT rotary head configuration at 600V AC.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the circuit before wiring or servicing the switch. Screw terminals must be tightened securely to prevent loose connections under vibration. Verify that the actuator travel and mounting orientation match the mechanical stroke of the application before final installation.
