Square D 9007ML02S0100 Limit Switch Spdt Nc Roller Plunger

Product Description

The SQUARE D 9007ML02S0100 is a general purpose limit switch rated for 240 volts AC, built with a side-mounted roller plunger actuator and a single-pole double-throw (SPDT) contact form in a normally closed (NC) configuration. The body is constructed from zinc and the unit ships prewired for fast installation. It carries an IP67 ingress protection rating, making it suitable for wet and dusty environments. Licensed electricians and industrial maintenance technicians install this switch in automation, conveyor, door position, and process control applications where reliable electromechanical position sensing is required.

The 9007ML02S0100 is suited for both light industrial and commercial installations where position or end-of-travel detection is needed. The side-mounted roller plunger actuator allows the switch to be tripped by a cam or moving machine member approaching from the side. The prewired termination reduces field wiring time. The wide operating temperature range of -40 degrees F to 220 degrees F makes it usable in outdoor enclosures, refrigerated spaces, and hot process environments alike. NEMA ratings of 1, 2, 4, 6, and 6P indicate suitability for general-purpose, drip-proof, watertight, and submersible enclosure applications.

Key Features

• SPDT contact form with normally closed (NC) configuration for fail-safe position sensing
• Side-mounted roller plunger actuator for lateral cam or machine member actuation
• IP67 ingress protection rating — dust-tight and protected against temporary immersion
• NEMA 1, 2, 4, 6, and 6P rated for a broad range of enclosure environments
• Zinc body construction for durability in industrial settings
• Prewired terminals reduce field wiring time during installation
• Operating temperature range of -40 degrees F to 220 degrees F

Compatibility

Designed as an OEM-style general purpose limit switch for industrial automation, conveyor systems, and machine control panels requiring a side-actuated roller plunger SPDT switch rated at 240 volts AC.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize all circuits and lock out the machine before mounting or wiring the switch. Verify actuator alignment with the tripping cam or machine member to ensure consistent actuation force does not exceed the 80-ounce maximum operating force rating. Confirm enclosure NEMA rating matches the installation environment before final mounting.
