Square D 9007FTUB1 Limit Switch Spdt Rotary Spring Return

Product Description

The SQUARE D 9007FTUB1 is a general purpose limit switch designed for industrial position-sensing and machine control applications. It uses a rotary spring-return actuator mounted on the side of the switch body and features an SPDT contact configuration with screw-type terminals. Rated for 600 volts AC, it is built with a zinc body and carries an IP67 ingress protection rating, making it suitable for environments where dust and temporary immersion are concerns. The actuator travel is 14 degrees. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

This limit switch is suited for use in manufacturing, material handling, and automated machinery where reliable position detection is required. The side-mounted rotary spring-return actuator allows the switch to detect mechanical movement and automatically reset to its default position when the actuator is released. The 1/2 inch NPT conduit connection supports standard electrical raceway installations. It is appropriate for both indoor and outdoor applications given its NEMA ratings of 1, 2, 4, 12, and 13.

Key Features

• SPDT contact form for standard normally-open and normally-closed circuit configurations
• Rotary spring-return actuator with 14-degree travel, side-mounted
• IP67 ingress protection rating resists dust and temporary water immersion
• 600V AC voltage rating for industrial control circuits
• Zinc body construction for durability in demanding environments
• NEMA ratings 1, 2, 4, 12, and 13 for broad environmental coverage
• RoHS compliant and tested to IEC 60068-2-27, IEC 60068-2-6, IEC 60529, IEC 61140

Compatibility

Designed as an OEM-style replacement or direct installation limit switch for industrial machine control systems requiring an SPDT rotary spring-return actuator with a 1/2 inch NPT conduit entry.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize all circuits and lock out the equipment before mounting or wiring the switch. The screw terminals and 1/2 inch NPT conduit connection require standard hand tools. Verify actuator alignment and travel clearance before restoring power to the controlled equipment.
