Square D 9007C54FH Limit Switch Spdt Nc Plunger

Product Description

The SQUARE D 9007C54FH is a general purpose limit switch designed to detect position or movement in industrial and commercial control systems. It features a top-mounted plunger actuator with a single-pole double-throw (SPDT) contact form and a normally closed (NC) contact configuration, making it suitable for machine guarding, conveyor control, and automated equipment interlocks. The switch is rated for up to 600 volts and has a zinc body construction. Terminal connections are screw type, which supports straightforward field wiring. Licensed electricians and industrial maintenance technicians are the typical installers for this device.

The 9007C54FH is suited for general purpose control applications in both light industrial and commercial environments. The plunger actuator is activated by direct mechanical contact from a moving machine component, triggering the switch at a preset travel point. Typical applications include door interlock circuits, end-of-travel detection on linear actuators, and position sensing on production equipment. The operating temperature range of 0 degrees F to 185 degrees F supports use in a broad range of indoor industrial environments.

Key Features

• Top-mounted plunger actuator for direct vertical actuation
• SPDT contact form with NC configuration for fail-safe circuit design
• 600-volt rating suitable for a wide range of control circuits
• Screw terminal connections for reliable field wiring
• Zinc body construction for durability in industrial environments
• UL Listed, CSA Certified, and CE marked

Compatibility

Designed as an OEM-style general purpose limit switch for use in industrial and commercial control panel and machine applications requiring SPDT plunger-actuated position sensing.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC guidelines. De-energize all circuits and lock out the equipment before wiring or mounting the switch. Confirm actuator travel alignment with the moving machine component before securing the switch body in place. Do not exceed the rated maximum operating force of 4.00 pounds on the plunger actuator during installation or operation.
