Square D 9007C52N Limit Switch Spdt Nc Roller Lever 600V

Product Description

The SQUARE D 9007C52N is a general purpose limit switch designed to detect the presence, position, or travel limit of mechanical components in industrial and commercial control systems. It uses a roller lever actuator to convert physical contact into an electrical signal, interrupting or completing a circuit as required. The switch features a single-pole double-throw (SPDT) contact form with a normally closed (NC) configuration and screw terminal connections. Rated at 600 volts, it is built into a zinc body and suits applications requiring durable, reliable position sensing. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

The 9007C52N is suited for use in machinery, conveyor systems, automated equipment, and other electromechanical control applications where physical travel or position must be monitored. The roller lever actuator accommodates cam-driven or surface-contact actuation with 4 degrees of travel. Its operating temperature range of -20 degrees F to 185 degrees F makes it appropriate for both indoor and light industrial outdoor environments. Screw terminals allow for straightforward field wiring with standard control conductors.

Key Features

• Roller lever actuator with 4-degree travel for reliable mechanical actuation
• SPDT contact form with NC configuration for standard position-sensing circuits
• 600-volt rating suitable for industrial control voltage applications
• Zinc body construction for durability in demanding environments
• Screw terminal wiring for secure, serviceable field connections
• CE, CSA Certified, and UL Listed for compliance with common electrical standards

Compatibility

Designed as an OEM-style replacement or new-installation limit switch for general purpose industrial control systems requiring an SPDT NC roller lever switch rated at 600 volts.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the control circuit before mounting or wiring this switch. Secure the switch body firmly to the mounting surface so the roller lever contacts the actuating cam or surface consistently throughout its travel range. Verify contact configuration and wiring continuity before restoring power to the control system.
