Square D 8965RO10V01 Reversible Dp Contactor 3 Pole 24V

Product Description

The SQUARE D 8965RO10V01 is a reversible definite purpose contactor designed for motor control applications in HVAC, refrigeration, and light commercial equipment. It features a 3-pole configuration with a 24 VAC coil rated at 60 Hz, making it compatible with low-voltage control circuits commonly found in commercial and industrial systems. The contactor handles both single-phase and three-phase loads across a range of voltages and horsepower ratings, giving technicians flexibility across multiple equipment types. It meets CSA, RoHS, and UL Listed standards, confirming it is built to recognized safety and compliance benchmarks. Installation is typically performed by licensed HVAC technicians or electricians servicing motor-driven equipment.

The 8965RO10V01 is suited for use in reversing motor control circuits where forward and reverse operation is required. Rated horsepower capacities include 1 HP at 115 VAC single-phase, 1.5 HP and 3 HP at 230 VAC, 3 HP at 460 VAC, and 3 HP at 575 VAC, covering a wide range of three-phase commercial and light industrial motor applications. It is commonly installed in rooftop units, air handlers, compressor racks, and other definite purpose motor loads that require reversing capability.

Key Features

• Reversible contactor design supports forward and reverse motor control in a single unit
• 3-pole configuration handles single-phase and three-phase loads
• 24 VAC coil at 60 Hz integrates with standard low-voltage control circuits
• Rated up to 3 HP at 230 VAC, 460 VAC, and 575 VAC three-phase
• CSA certified, RoHS compliant, and UL Listed for verified safety compliance

Compatibility

Designed as an OEM-style replacement reversible definite purpose contactor for use in residential and commercial motor control applications where a 3-pole, 24 VAC coil contactor is specified.

Installation Notes

Installation should be performed by a licensed electrician or qualified HVAC technician. De-energize and lock out the equipment at the disconnect before removing or installing the contactor. Verify coil voltage and pole configuration match the application requirements before wiring. Follow applicable NEC guidelines for motor control circuit installations.
