Square D 8501NR42 Relay Socket 300 VAC 10 Amp Din Rail/Direct Panel Mount Double Tier

Product Description

The Square D 8501NR42 relay socket is designed for wiring 8501R plug-in relays and can be mounted on a 35mm DIN rail or directly to a panel. The 8501RS42 or 8501RSD42 relay will plug into this relay socket which is designed for 8 blade pins. The socket terminals feature pressure wire clamps for a secure connection and has stacked terminals to save panel space.

• UL Component Recognized and CSA Certified
• Designed for use with 8501 K plug in relays and 8501R miniature plug in relays
• Pressure wire connectors

Product Highlights

The Square D 8501NR42 relay socket is suitable for use with 8501RS(D)42 relays and features screw clamp connections.

Product Information

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: 8501NR42
• Country of Origin: China

Technical Specifications

• Type: Relay Socket
• Brand: Square D
• Depth: 25.27 mm
• Width: 29.92 mm
• Height: 69.09 mm
• Mounting Type: DIN Rail,Panel
• Certifications: CE,CSA,UL Recognized
• Number of Pins: 8
• Line Rated Current: 10 A
• Catalog Number: 8501NR42
• Manufacturer: Schneider Electric
• Country of Origin: China
• Made in USA: No
• UPC: 785901097846
• GTIN: 00785901097846
• Contact Rating: 300 V 10 Ampere
• Terminal Type: Screw Clamp
• Used On: 8501K/R Series Plug-In Relay, 8430 MPS Phase Failure Relay, 9050JCK Timer
• Wire Size: 22 to 12 AWG
• Amps: 10
• Volts: 300
• Connection Type: Double tiered screw clamp terminals
• Current: 10A
• Voltage: 300V AC
• Mounting: Panel;DIN rail
• Electrical Connection: Double tiered screw clamp terminals
• Series: 8501N
• Suitable For Use With: 8501RS(D)42 Relay
• Manufacturer Name: Schneider Electric
• Primary Type: Relay Sockets
