Square D 50SV43A Buck Boost Transformer 0.05 Kva

Product Description

The SQUARE D 50SV43A is a single-phase buck boost transformer rated at 0.05 kVA, designed to raise or lower line voltage by a fixed increment rather than provide full isolation. It accepts 120 or 240 volt input and delivers 12 or 24 volt boost or buck output at 60 Hz. Housed in a NEMA 3R enclosure, it is rated for both indoor and outdoor installation, offering protection against rain and sleet. Electricians install this unit where minor voltage corrections are needed — typically to compensate for voltage drop over long feeder runs or to bring supply voltage into acceptable range for sensitive loads. The unit is RoHS compliant.

This transformer suits residential and light commercial electrical applications where a small, fixed voltage adjustment is required. Typical scenarios include correcting low or high line voltage feeding motors, HVAC equipment, lighting circuits, or control circuits. Its compact form factor and weatherproof NEMA 3R rating make it practical for installations in mechanical rooms, rooftop equipment enclosures, or exterior panels where exposure to the elements is a concern.

Key Features

• 0.05 kVA power rating for small fixed-increment voltage correction applications
• 120 or 240 volt input with 12 or 24 volt buck or boost output at 60 Hz
• Single-phase design suitable for residential and light commercial systems
• NEMA 3R rated enclosure approved for indoor and outdoor use
• RoHS compliant construction

Compatibility

Designed as an OEM-style replacement or direct-install buck boost transformer for single-phase 120/240 volt electrical systems requiring minor fixed voltage adjustment.

Installation Notes
