Sprecher & Schuh V7-W6 Terminal Feedthrough (1 Level 2 Conductor)

Product Description

The Sprecher & Schuh V7-W6 is a terminal feedthrough for the S+S V7-W terminal block family. It is a single-level screw-connection feed-through with two conductor entries, designed for 35 mm DIN rail mounting and rated for 41 A and 800 V. The terminal accepts 0.5–6 mm² conductors with 12 mm strip length and uses a nominal tightening torque of 0.7 Nm. Dimensions are 7 mm x 47.6 mm x 41 mm.

• Screw-connection feed-through, single level with 2 conductor entries; rated current 41 A and rated voltage 800 V
• Accepts 0.5–6 mm² conductors, 12 mm wire strip length; nominal tightening torque 0.7 Nm
• Mounts to 35 mm DIN top hat rail; dimensions 7 mm (W) x 47.6 mm (H) x 41 mm (D); operating −40 to 90 °C

Product Highlights

Feed-through terminal for V7 series; 2 conductor entries; 41 A, 800 V; accepts 0.5–6 mm²; DIN-rail mount

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: V7-W6

Technical Specifications

• Brand: Sprecher & Schuh
• MPN: V7-W6
• Product family: V7 (V7-W)
• Product type: Feed-through terminal block
• Component type: Terminal feedthrough
• Connection type: Screw connection
• Rated current: 41 A
• Rated voltage: 800 V
• Number of levels: 1
• Clamp positions per level: 2
• Wire conductor size: 0.5–6 mm²
• Wire strip length: 12 mm
• Nominal tightening torque: 0.7 Nm
• Mounting method: DIN rail (35 mm top hat)
• Width: 7 mm
• Height: 47.6 mm
• Depth: 41 mm
• Operating temperature: -40 to 90 °C
• Insulation temperature: -40 to 90 °C
• Color: Grey
• Category: Terminal blocks
• Manufacturer product status: Commercialized
