Sprecher & Schuh L9-2/1/C L9 protector 2 A (1 Pole)

Product Description

Sprecher & Schuh L9-2/1/C is a miniature single-pole circuit protector providing thermal-magnetic protection at 2 A with a C (Curve C) trip characteristic. It is rated for up to 277 VAC and 48 VDC and has a 10 kA interrupt rating, suitable for DIN-rail mounting with screw terminals and UL/CSA/CE approvals for branch circuit protection.

• 2 A current rating, C (Curve C) trip characteristic, 10 kA interrupt rating
• Rated voltages: 277 VAC and 48 VDC; single-pole thermal-magnetic trip unit
• DIN rail mounting with screw terminals; approvals UL, CSA, CE; IP20 enclosure

Product Highlights

Miniature DIN-rail circuit breaker, 1 pole, thermal-magnetic trip, 2 A, 277 VAC/48 VDC, 10 kA interrupt, UL/CSA/CE approvals

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: L9-2/1/C
• Country of Origin: United States

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer Part Number: L9-2/1/C
• Series: L9
• Product Name: L9 protector (miniature circuit breaker)
• Current Rating: 2 A
• Rated Voltage: 277 VAC; 48 VDC
• Interrupt Rating: 10 kA
• Poles: 1
• Trip Characteristic: Type C (Curve C)
• Trip Unit: Thermal magnetic
• Mounting: DIN rail
• Terminal Type: Screw
• Approvals: UL; CSA; CE
• Enclosure Rating: IP20
• Dimensions: 4.37 in H x 0.69 in W x 2.72 in D
• Net Weight: 0.275 lbs
• Gross Weight: 0.28 lbs
• Optional Accessories: Auxiliary switch; shunt trip; lock-off attachment (available)
• Features: Trip free mechanism; color-coded handle for status indicators; thermal magnetic protection
• UNSPSC: 39121603
