Sprecher + Schuh KTA9-32S-4.0A motor protection circuit breaker 4 amp

Product Description

The Sprecher + Schuh KTA9-32S-4.0A motor protection circuit breaker provides a compact solution for protecting motors against overload, short circuit, and phase failure. Designed for industrial environments, it combines a manual motor starter and a thermal-magnetic circuit breaker. It is ideal for motor control panels and machinery.

• Combines adjustable thermal overload and fixed magnetic short-circuit protection
• Available in ratings up to 32A to suit various motor sizes
• Trips the breaker in the event of phase failure

Product Highlights

The KTA9 series ensures motors and operations are well-protected with adjustable overload protection, fast magnetic trip response, and built-in phase-loss sensitivity.

Product Information

Standard Information

• Brand: SPRECHER + SCHUH
• Manufacturer Part Number: KTA9-32S-4.0A
• Country of Origin: Mexico

Technical Specifications

• Brand: Sprecher + Schuh
• MPN: KTA9-32S-4.0A
• Condition: New
• Country of Origin: Mexico
• Manufacturer Part Number: PN-495040
• Manufacturer: Sprecher + Schuh
• Product Series: KTA9
• Family Series: Sprecher + Schuh Manual Motor Protectors, KTA9 Series
• Description: 4A Motor Protection Circuit B
• Current Rating: 4 A
• FLA Adjustment Range: 2.5-4
• Phase: 3
• Poles: 3
• Trip Class: Class 10
• Auxiliary Contact: None
• Enclosure: Open
• Operator: Rotary
• Pilot Light: No
• Protection Rating: IP2X
• Approvals: CCC, CE, CSA, cULus, IEC, UL
• Comments: KTA9-32S Standard Interrupting Capacity
• All - Voltage: 200 to 575VAC
• Amp Rating: 4 Amp
• Short Circuit Capacity: 65kA
• Trip Curve: Magnetic Trip
• Circuit Breaker Type: Manual Motor Protector (MMP)
