Sprecher + Schuh CDP2-B3P40A-24 Contactor 40A (3-P)

Product Description

Sprecher + Schuh CDP2-B3P40A-24 is a definite purpose contactor with a 24 VAC coil and three power poles rated 40 A. It is part of the CDP2 series designed for commercial HVAC, refrigeration and resistive heating applications and the series is rated up to 600 VAC. The device uses a non-latching coil and offers multiple termination methods including box lugs, quick-connects and screws.

• 24 VAC nominal coil voltage; non-latching coil with Class B (130°C) insulation
• Three poles with 40 A rated current; double-break power contact design and feed-thru wiring
• Multiple terminations (box lug, quick connect, screw), universal mounting plate; approvals CE, CSA, UR

Product Highlights

3-pole definite purpose contactor, 24 VAC coil, 40 A rating, enclosed frame B, multiple termination options

Product Information

Standard Information

• Brand: SPRECHER + SCHUH
• Manufacturer Part Number: CDP2-B3P40A-24

Technical Specifications

• Manufacturer: Sprecher + Schuh
• Manufacturer Part Number: CDP2-B3P40A-24
• Product Series: CDP2
• Description: Contactor, 3-pole, 40 A, 24 VAC coil
• Number of Poles: 3
• Rated Current: 40 A
• Coil Voltage: 24 VAC
• Coil Type: Non latching
• Coil Insulation Class: Class B (130°C)
• Frame Size: B
• Termination: Box lug, quick connect, screw
• Enclosure: Enclosed
• Contact Design: Double break power contact with feed-thru wiring
• Series Voltage Rating: Up to 600 VAC
• Approvals: CE, CSA, UR
• Mounting Type: Universal mounting plate
• Net Weight: 1.005 lbs
