Sprecher & Schuh CA7-PA-02 Auxiliary Contact 10A 600V (Side Mount 2-Pole) 22-401-230-01

Product Description

The Sprecher & Schuh CA7-PA-02 is a side-mount auxiliary contact block for CA7 series contactors. It provides two normally closed (2 NC) contacts in a 2-pole configuration, rated 10 A at 600 V and compatible with electronic loads down to 24 V, 20 mA. The snap-on design supports two-way numbering for right or left mounting and includes contact mapping for integration with CA7 contactors.

• Side-mount auxiliary contact block for CA7 series; snap-on mounting with two-way numbering
• 2 NC (two normally closed) contacts, 2-pole; contact mapping 11/42-12/41, 21/32-22/31
• Contact rating 10 A at 600 V; electronic-compatible to 24 V, 20 mA; approvals CCC, CE, cULus

Product Highlights

Side-mount 2 NC auxiliary contact block, 2-pole, 10 A/600 V rating, snap-on mounting for CA7 contactors.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CA7-PA-02

Technical Specifications

• Brand: Sprecher & Schuh
• Manufacturer Part Number: CA7-PA-02
• Manufacturer Item Number: 22-401-230-01
• Item Number: CA7-PA-02
• Product Type: Auxiliary contact block
• Catalog Description: CA7 Auxiliary Contact Side Mount 2NC 2-Pole
• Compatible Series: CA7 series contactors
• Mounting Type: Side mount (snap-on)
• Contact Configuration: 2 NC (two normally closed), 2-pole
• Contact Mapping: 11/42-12/41, 21/32-22/31
• Contact Current Rating: 10 A
• Contact Voltage Rating: 600 V
• Electronic Compatibility: 24 V, 20 mA
• Approvals: CCC, CE, cULus
• Net Weight: 0.08 lb
• Dimensions: 3 x 2 x 1 inches
• Two-way Numbering: Right or left mounting
• Late Break/Early Make Option: L available
• SKU: 2355019
• UPC: 00886739486090
• ASIN: B00SU02MR6
