Sprecher & Schuh CA7-30E-00-24E Contactor 30 A

Product Description

The Sprecher & Schuh CA7-30E-00-24E is a CA7 series IEC contactor rated at 30A with a 24V DC electronic coil and no auxiliary contacts. This open-type contactor is designed for panel mounting. It features mechanically linked contacts and is suited for motor switching in process control and industrial facilities.

• Rugged, space-saving, and modular design
• Lighter, lower depth
• More energy-efficient contactors

Product Highlights

The CA7 contactors control motors up to 75HP and are mechanically and electrically compatible with Sprecher + Schuh CEP7 electronic overload relay and KT9 motor circuit controller.

Product Information

Standard Information

• Brand: SPRECHER & SCHUH
• Manufacturer Part Number: CA7-30E-00-24E

Technical Specifications

• Manufacturer Part Number: CA7-30E-00-24E
• Manufacturer: Sprecher + Schuh
• Product Series: CA7
• Family Series: Sprecher + Schuh Contactors, CA7 Series
• Description: IEC Contactor 30 A
• Type: AC Non-Reversing IEC
• Nominal Coil Voltage: 24 VDC
• Coil Voltage: 24 VDC
• Coil Type: Non Latching
• Poles: 3
• Frame Size: CA7
• Auxiliary Contact: None
• Termination: Screw
• General Purpose (AC1): 65 A
• UL Motor Switching (AC3): 30 A
• Approvals: CCC, CSA, cULus
• Number of Poles: 3
• Series: CA7 Series
• Category: Contactor
