Spi 98-358-5 Indicator Transfer Stand Rectangular Base

Product Description

The SPI 98-358-5 is a rectangular-base indicator transfer stand designed for precision measurement setups in machining, metrology, and quality control environments. The stand uses a post-and-rod arm style and stands 14.125 inches tall overall, providing ample clearance for dial indicator positioning across a range of workpiece heights. A heavy-duty mechanical lock secures the arm at the desired position, maintaining indicator placement during measurement. The base measures 2.25 inches in length, 2 inches in width, and 2.125 inches in height, providing a stable footprint on surface plates and machine tables. Fine adjustment capability allows precise positioning of the indicator without repositioning the entire stand. This unit ships without a dial indicator, anvil, or holder.

This stand is suited for use in machine shops, tool rooms, and inspection departments where dial indicator transfer measurements are performed regularly. It is compatible with standard surface plate setups and is commonly used by machinists and quality control technicians performing part inspection, runout checks, and comparative measurement tasks. The rectangular base is well suited to flat reference surfaces such as granite or cast iron surface plates.

Key Features

• Post-and-rod arm style for versatile indicator positioning
• Heavy-duty mechanical lock holds arm position securely during measurement
• Fine adjustment mechanism for precise indicator placement
• Rectangular base for stable placement on surface plates and machine tables
• Certificate of Calibration traceable to NIST included
• Does not include dial indicator, anvil, or holder — compatible with separately sourced components

Compatibility

Designed as a general-purpose indicator transfer stand for use with standard dial indicators and holders sourced separately. No specific model compatibility data was provided by the manufacturer for this SKU.

Installation Notes

Setup is performed by machinists or metrology technicians and requires no power or special tooling. Place the base on a clean, flat reference surface such as a surface plate or machine table before securing the arm lock. Engage the heavy-duty mechanical lock only after the arm and indicator are positioned to avoid shifting the setup. Ensure the reference surface is free of chips or debris that could affect base seating and measurement accuracy.
