Spi 34-510-8 Threaded Ring Gage M24x2 Metric Class 6G No Go

Product Description

The SPI 34-510-8 is a single-ring threaded ring gage designed to verify external metric threads to a Class 6G No Go tolerance standard. Manufactured from Oil Hardened Non-Shrinking Steel (OHNS), this gage provides the dimensional stability and wear resistance required for accurate, repeatable thread inspection in production and quality-control environments. The No Go function confirms that a threaded workpiece does not exceed the maximum material condition, rejecting out-of-tolerance parts before they leave the shop floor. An NPL Traceability Certification is included, supporting compliance with documented quality management systems.

This gage is used for inspecting M24 x 2.00 externally threaded components in manufacturing, machining, and assembly operations. It is suited for both job shop and production floor use wherever metric Class 6G thread verification is required. Quality control technicians, machinists, and inspection personnel install and use this gage as part of standard go/no-go thread verification procedures. The included NPL traceability certification supports ISO and AS9100 quality documentation requirements.

Key Features

• No Go ring gage for M24 x 2.00 metric external threads, Class 6G tolerance
• Manufactured from Oil Hardened Non-Shrinking Steel (OHNS) for dimensional stability and long service life
• Single-ring design for dedicated No Go thread inspection
• NPL Traceability Certification included for quality system compliance
• UNSPSC Code 41111619 for procurement classification

Compatibility

Designed for inspection of externally threaded components with M24 x 2.00 metric threads manufactured to Class 6G tolerance specifications.

Installation Notes

Thread ring gages are used by machinists and quality control inspectors and require no permanent installation. Before use, clean the gage and the threaded workpiece to remove chips, oil, or debris that could affect readings. A properly calibrated No Go gage should not thread fully onto a conforming workpiece — if it does, the part is out of tolerance. Store the gage in its protective case when not in use and re-calibrate on a schedule consistent with your quality management system requirements.
