Spi 23-164-7 Truncated Taperlock Thread Plug Gage 3/8-16 Unc

Product Description

The SPI 23-164-7 is a truncated taperlock thread plug gage designed to verify 3/8-16 UNC internal threads to Class 2A tolerance. It includes both Go and No Go members, allowing a technician or quality inspector to confirm that a threaded hole is within the correct tolerance range in a single tool set. The gage is constructed from tool steel for durability and dimensional stability under repeated use. The included 2-inch handle provides a standard grip for controlled insertion. This type of gage is a staple in machining, fabrication, and assembly inspection environments where thread quality must be verified to print.

This gage is used in manufacturing, maintenance, and quality control applications wherever 3/8-16 UNC threaded holes must be inspected for conformance. It is appropriate for both production-line inspection and field verification work. The Go member confirms the hole accepts a mating fastener within tolerance; the No Go member confirms the hole has not been overcut. It is suited for use in metalworking shops, industrial assembly lines, and precision fabrication facilities.

Key Features

• Go and No Go members included for complete tolerance verification in one set
• Class 2A classification for standard unified coarse thread inspection
• Tool steel construction for dimensional stability and long service life
• Truncated taperlock design for secure, repeatable member seating in the handle
• 2-inch handle included for controlled, consistent insertion force
• Covers 3/8-16 UNC thread specification

Compatibility

Designed for inspection of 3/8-16 UNC internal threads to Class 2A tolerance. The taperlock handle is compatible with standard taperlock-style gage members of the appropriate size range.

Installation Notes
