SPEARS A435BL-32 2 IMP 304L 150# RF BLIND FLG

Product Description

The SPEARS A435BL-32 is a blind flange designed for use in piping systems. This flange connects two pipe sections or valves effectively. Made from 304/304L stainless steel, it meets ASTM A182 standards. It has a forged construction and a pressure rating of Class 150, adhering to ANSI B16.5 and ASME SA182 standards. The design features bolted connections that enable ease in installation and removal.

• Crafted for connecting pipe sections or valves.
• Facilitates mobility in piping systems through bolted connections.
• Compliant with RoHS and REACH standards.

Product Highlights

The SPEARS A435BL-32 supports stable installations and prevents leakage due to its robust design.

Product Information

Standard Information

• Type: Blind
• Nominal Pipe Size: 2 Inch

Technical Specifications

• Flange Outside Diameter: 6 Inch
• Thickness: 0.75 Inch
• Material: 304/304L Stainless Steel
• Material Specification: ASTM A182
• Process: Forged
• Pressure Rating Class: 150
• Applicable Standard: ANSI B16.5, ASME SA182
• Raised Face Outer Diameter: 3.62 Inch
• Diameter at Base of Hub: 3.06 Inch
• Number of Holes: 4
• Bolt Circle Diameter: 4.75 Inch
• Hole Diameter: 0.75 Inch
• Bolt Diameter: 5/8 Inch
